Tabletop Stands

Specifications

• Technical

  ---

  Part Number(s)

  Black/Silver Tabletop Stands:
  E307788 - Tabletop Stand for 0702L, 1002L, 1302L, 1502L, 1502LM, 10” and 15” Android I-Series 2/3/4
  E804330 - Tabletop Stand for 1902L, 1903LM, 2002L, 2202L, 2203LM, 15” and 22” Android I-Series 2/3/4
  E509844 - Tabletop Stand for 2402L, 2403LM, 2702L, 2703LM, 15” and 22” Android I-Series 2/3/4

  Black Tabletop Stands
  E044162 - Tabletop Stand for 1502L, 1502LM, 15” Android I-Series 2/3/4, 15” Windows I-Series 2.0
  E044356 (Compatible with rear-facing display pole mount kit E038989) - Tabletop Stand for 1502L, 1502LM, 2002L, 15” and 22” Android I-Series 2/3/4, 22” Windows I-Series 2.0

  White Tabletop Stands
  E307974 - Tabletop Stand for 1302L, 1502LM, 10” and 15” Android I-Series 2/3/4
  E765019 - Tabletop Stand for 1502LM, 15” Android I-Series 2/3/4
  E808963 - Tabletop Stand for 1903LM, 2203LM, 15” and 22” Android I-Series 2/3/4
  E510042 - Tabletop Stand for 2403LM, 2703LM, 15” and 22” Android I-Series 2/3/4

  Enclosure Color

  Black

  Compatibility

  Tabletop Stands for 0702L - E307788

  Tabletop Stands for 1002L - E307788

  Tabletop Stands for 10-inch I-Series for Android (2/3/4) - E307788, E307974 (Install all cables before mounting to the stand)

  Tabletop Stands for 1302L - E307788, E307974

  Tabletop Stands for 1502L - E307788, E044162, E044356

  Tabletop Stands for 1502LM - E307788, E044162, E044356, E307974, E765019

  Tabletop Stands for 15-inch I-Series for Android (2/3/4) - E044162, E044356, E765019 / E307788, E307974 (Install all cables before mounting to the stand) / E804330, E509844, E808963, E510042 (M4x10L mounting screws are recommended)

  Tabletop Stands for 15-inch I-Series for Windows (2.0) - E044162 (Requires adaptor kit E388675)

  Tabletop Stands for 1902L - E804330

  Tabletop Stands for 1903LM - E804330, E808963

  Tabletop Stands for 2002L - E804330 (M4x12L mounting screws are recommended), E044356

  Tabletop Stands for 2202L - E804330

  Tabletop Stands for 2203LM - E804330, E808963

  Tabletop Stands for 22-inch I-Series for Android (2/3/4) - E044356 / E804330, E509844, E808963, E510042 (M4x10L mounting screws are recommended)

  Tabletop Stands for 22-inch I-Series for Windows (2.0) - E044356 (M4x14L mounting screws are recommended)

  Tabletop Stands for 2402L - E509844

  Tabletop Stands for 2403LM - E509844, E510042

  Tabletop Stands for 2702L - E509844

  Tabletop Stands for 2703LM - E509844, E510042

  Mounting Options

  E307788, E307974: 75 x 75mm VESA
  E044162, E765019, E044356, E804330, E808963, E509844, E510042: 100 x 100mm VESA

  Dimensions

  E307788, E307974: 10.2" x 5.9" x 8.1" / 260 mm x 150.2 mm x 205 mm
  E044162, E765019: 10.5" x 7.8" x 8.6" / 266.4 mm x 199.1 mm x 219.7 mm
  E044356: 10.7" x 9.9" x 10.2" / 272.8 mm x 251.7 mm x 260.2 mm
  E804330, E808963: 15.0" x 7.6" x 10.4" / 380 mm x 193.4 mm x 263.2 mm
  E509844, E510042: 15.0" x 8.5" x 11.8" / 380 mm x 215 mm x 299.1mm

  Shipping Box Dimensions

  E307788, E307974: 12.8" x 8.86" x 11.22" / 325 mm x 225 mm x 285 mm
  E044162, E765019: 13.39" x 11.42" x 9.45" / 340 mm x 290 mm x 240 mm
  E044356: 13.39" x 9.65" x 13.78" / 340 mm x 245 mm x 350 mm
  E804330, E808963: 18.03" x 10.94" x 12.24" / 458 mm x 278 mm x 311 mm
  E509844, E510042: 18.39" x 11.81" x 15.35" / 467 mm x 300 mm x 390 mm

  Weight (Unpackaged)

  E307788, E307974: 2.43 lbs / 1.1 kg
  E044162, E765019: 3.31 lbs / 1.5 kg
  E044356: 5.53 lbs / 2.51 kg
  E804330, E808963: 4.41 lbs / 2 kg
  E509844, E510042: 7.1 lbs / 3.22 kg

  Weight (Packaged)

  E307788, E307974: 3.48 lbs / 1.58 kg
  E044162, E765019: 4.41 lbs / 2 kg
  E044356: 8.22 lbs / 3.73 kg
  E804330, E808963: 6.61 lbs / 3 kg
  E509844, E510042: 8.53 lbs / 3.87 kg

  Warranty

  2-year

  What's in the Box

  E307788, E307974, E044356: Stand, Installation Flyer, 4x M4x10L Flat-Head screws
  E044162, E765019: Stand, Installation Flyer, 4x M4x10L Pan-Head screws
  E804330, E808963, E509844, E510042: Stand, Installation Flyer, 4x M4x15L Flat-Head screws
